Name: JMZ-T Series Spring Isolator with Up to 95% Isolation Efficiency for Precision Manufacturing
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-T1-0.3
Availability: InStock

المنزل > المنتجات > عازل الربيع >

JMZ-T Series Spring Isolator with Up to 95% Isolation Efficiency for Precision Manufacturing

JMZ-T Series Spring Isolator,95% Isolation Efficiency Spring Isolator,Precision Manufacturing Spring Isolator

95% Isolation Efficiency Spring Isolator

Precision Manufacturing Spring Isolator

مكان المنشأ:

الصين

اسم العلامة التجارية:

Hoan

رقم الموديل:

JMZ-T1-0.3

اتصل بنا

اطلب اقتباس

JMZ-T Series Spring Isolator with Up to 95% Isolation Efficiency for Precision Manufacturing

تفاصيل المنتج

التوافق:

متوافق مع أنواع مختلفة من الآلات والمعدات

متانة:

طويل الأمد

قابلية ضبط:

قابل للتعديل

الحد من الضوضاء:

فعال

سمات:

سعة حمولة عالية ، عزل اهتزاز ممتازة ، متينة

أبعاد:

أحجام مختلفة متاحة

لون:

فضي

تقرير اختبار الآلات:

غير متوفر

كفاءة العزلة:

حتى 95٪

نموذج:

جمز-T

الاستخدام:

عزل الاهتزاز

صيانة:

قليل

مقاومة الصدمة:

قوي

إبراز:

JMZ-T Series Spring Isolator,95% Isolation Efficiency Spring Isolator,Precision Manufacturing Spring Isolator

95% Isolation Efficiency Spring Isolator

Precision Manufacturing Spring Isolator

شروط الدفع والشحن

الحد الأدنى لكمية

شروط الدفع

L/C ، D/A ، D/P ، Western Union ، Moneygram ، T/T.

منتجات ذات صلة

JMZ-T1-1.4 32mm Overall Width Spring Isolator with 1 Year Warranty and High Resilience for Industrial Vibration Isolation

احصل على أفضل سعر

JMZ-T1-1.2 Spring Isolator with 95% Isolation Efficiency 32mm Overall Width and UL Listed for Vibration Isolation

احصل على أفضل سعر

JMZ-T1-0.6 Spring Isolator with High Resilience and Strong Shock Resistance for Durable Vibration Control

احصل على أفضل سعر

JMZ-T1-0.45 Friction Damping Vibration Isolator with Up to 95% Isolation Efficiency for 0-150°F Operating Temperature and 1 Year Warranty

احصل على أفضل سعر

اتصل بنا

86-29-88292913

اتصل بنا الآن

وصف المنتج

Precision Manufacturing Laboratory Measurement and High-End Communications Vibration Isolation with JMZ-T1-0.3

JMZ-T1 Series: Advanced Vibration Isolation Technology

In precision manufacturing, laboratory measurement, and high-end communications, environmental vibrations can significantly impact equipment performance. The JMZ-T1 Series vibration isolator from Xi'an Hoan Microwave provides an innovative solution to this challenge.

Unlike traditional vibration isolation methods, our friction damping technology acts like a "Tai Chi grandmaster," converting destructive mechanical energy into negligible thermal energy. This process creates an "absolute static zone" for sensitive equipment, ensuring:

Elimination of vibration interference from footsteps, vehicles, and HVAC systems
Protection for nanoscale precision equipment like lithography machines
Clear imaging for electron microscopes and other sensitive instruments
Effective filtering across low to mid-high frequency vibration spectra

Structural Dimensions

Technical Specifications

Model	Max PZ-Direction Load (kg)	PZ Displacement Under Max Load (mm)	H (mm)	h (mm)	d (mm)	Weight (g)	Shock Test	Resonance Frequency (Hz)	Operating Temperature Range (°C)
JMZ-T1-0.3	0.3	≤0.6	19.5±0.5	16	M4-7H/ M3-7H	≤58	30g,11ms	＜30	-65～+120
JMZ-T1-0.45	0.45
JMZ-T1-0.6	0.6
JMZ-T1-1.2	1.2		22±0.5	17.5
JMZ-T1-1.4	1.4
JMZ-T1-2.0	2.0

Performance Characteristics

Vibration Isolation Performance

Impact Resistance Performance
